Display Size:21.3”

Resolution:2048x1536

Support hotline:+86 400-1818-992

Get a quote
Product reselection

Product Description

G32S+ is with 3MP (2048X1536) high resolution, high brightness, high contrast ratio and wide viewing angle, build-in 14bits LUT, can be applied to various medical image equipment and PACS system. Each monitor is strictly calibrated to compliant with DICOM standard, ensure the accurate display of medical images and details. The built-in backlight stabilization system can ensure the consistence performance in long-term use.

G32S+ is with LED backlight and ultra-thin design.

C53S+

Feature Highlights

Ambient Light Adaptive System

With built-in integrated front ambient sensor, the ambient environment can be monitored continuously, the brightness can be adjusted to a proper level automatically to ensure the display is compliant with DICOM standard under any ambient environment The diagnostic accuracy is increased and discomfort and eye-strain can also be avoided.

Backlight Stabilization System

With built-in integrated back light sensor, the backlight can be monitored continuously. This achieves stable brightness rapidly at start-up and automatically compensate the brightness fluctuations caused by ambient temperature change and luminance attenuation after long time usage. The brightness uniformity of the display can be maintained throughout the entire life cycle.

Compliant With DICOM Standard

Medical images including the most subtle details can be displayed precisely. Keep display consistency between different displays as well as display and different imaging modalities, ensure the accuracy of diagnosis.

Continuous Quality Assurance System

With integrated front sensor, grayscale and color can be monitored and calibrated. The display accuracy of medical image is continuous automatically assured, and can also be network centralized managed.

Technical Specification
Product modelG32S+
Product name3MP Grayscale Medical Display
Display size21.3''
Support color1024 grayscale
Resolution2048×1536
View angle178° Typ.
Brightness2000cd/m² Typ.
Contrast ratio1500:1 Typ.
Input signal interfaceDVI-D: 24 pin; DisplayPort: 20 pin
