Display Size:30"

Resolution:3280x2048

Support hotline:+86 400-1818-992

Product Description

Implementing dual screen display function on the same monitor ensures consistency in medical image comparison, suitable for diagnosis and comparative analysis of various medical images, improving the accuracy of doctors' diagnosis and improving their work efficiency.

C616W can display two medical images perfectly with one screen and make more accurate comparison, it can be applied into various of medical imaging diagnoses and comparison analyses, improve the diagnostic accuracy and working efficiency. Multifunctional configuration covers diagnosis application scenarios, including spotlight, backlight, spotlight, KVM control, picture self-test, intelligent control software, etc.

C53S+

Feature Highlights

Low Blue Light Technology

Blue light is a part ofthe short-wave light in the spectrum, which is abundant in the normal display screen. Long-term exposure to blue light is the main cause of maculopathy. The main symptoms of maculopathy are central visual impairment and visual deformity. Over 50% of the blue light can be cut down by low blue light technology, the risk of macular degeneration can be significantly reduced.

KVM Function

support switching and enabling the KVM function with one button. Two workstations are connected, which share the mouse and keyboard.

Backlight Stabilization System

With built-in integrated back light sensor, the backlight can be monitored continuously. This achieves stable brightness rapidly at start-up and automatically compensate the brightness fluctuations caused by ambient temperature change and luminance attenuation after long time usage. The brightness uniformity of the display can be maintained throughout the entire life cycle.

Split Screen Independent GAMMA

The brightness requirements of images and reports are different, and the split-screen independent GAMMA can be adjusted to the appropriate brightness according to the display object, which is convenient for doctors to view images and reports at the same time, without causing eye discomfort due to brightness.

Technical Specification
Product modelC616W
Product name6MP Integrated Dual-screen Display
Display size30"
Support color1.07 billion
Resolution3280×2048
View angle178° Typ.
Brightness1300cd/m² Typ.
Contrast ratio2000:1 Typ.
Input signal interfaceDVI-D: 24 pin*2; DisplayPort: 20 pin*2;
VGA: D-sub 15 pin
