E190
E190
Display Size：19”
Resolution：1280×1024
Support hotline：+86 400-1818-992
Get a quoteBacklight Stabilization System
With built-in integrated back light sensor, the backlight can be monitored continuously. This achieves stable brightness rapidly at start-up and automatically compensate the brightness fluctuations caused by ambient temperature change and luminance attenuation after long time usage. The brightness uniformity of the display can be maintained throughout the entire life cycle.
Product Description
E190 is a high-performance full-HD endoscopic surgical medical monitor specially designed for operating rooms.
It has the characteristics of high brightness, high contrast, and wide viewing angle. After connecting with the surgical endoscope system, doctors and staff in the operating room can see smooth, clear and true full HD surgical images.
Ultra-low reflection, real color, more detailed pictures, provide doctors with accurate and realistic visual experience.
Wide viewing angle
IPS or IPS-PRO panel will be ideal option for surgical imaging, as IPS or IPS-PRO technology performs wider viewing angle with better contrast ratio and color reproduction.
Compliant with DICOM Standard
Medical images including the most subtle details can be displayed precisely. Keep display consistency between different displays as well as display and different imaging modalities, ensure the accuracy of diagnosis.
| Product model | E190 |
| Product name | Endoscopy Display |
| Display size | 19" |
| Support color | 16.7 million |
| Resolution | 1280×1024 |
| Viewing angle | 178° Typ. |
| Brightness | 300 cd/m² Typ. |
| Contrast | 1000:1 Typ.video |
| Input signal interface | DVI-D*1， RGBS*1，CVBS*1，S-video*1 |
